Functions compatible with the 2016 Nissan Rogue (Smart Key)
*Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro.
* Odometer
Arm Factory Security
Brake Status (foot brake)
Control of aftermarket alarm with OEM remote
Disarm Factory Security
Door Lock Control
Door Locks Status
Door Unlock
E-Brake Status
Entry Monitoring ALL Door Pins
Entry Monitoring Hood Pin
Entry Monitoring Trunk/Hatch Pin
Factory Alarm Trigger Monitoring
Fuel level/EV battery level
Ignition Status
Immobilizer Bypass-Data No Key Req'd
Parking Lights Control
Remote Start Ready
Remote Start Takeover
SmartStart
Tach / RPM Output
Trunk / Hatch Release
403.NISS06
v3.27
2016 Nissan Rogue (Smart Key)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIRECTECHS DB3 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed DIRECTECHS DB3

Summary of Contents for Directed DIRECTECHS DB3

  • Page 1 403.NISS06 v3.27 2016 Nissan Rogue (Smart Key) Functions compatible with the 2016 Nissan Rogue (Smart Key) *Telematics features: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart Pro. * Odometer Entry Monitoring Trunk/Hatch Pin Arm Factory Security Factory Alarm Trigger Monitoring Brake Status (foot brake) Fuel level/EV battery level...
