Measurement board (optional)
The Measurement board connects between the Emulation Adapter and the Conversion board.
Embedded targets often do not have access to all the MCU pins / connected signals to connect
with measurement equipment (oscilloscope, logic analyzer), its use provides easy access to all
MCU pins. It is delivered together with an Layout board (chip signals are clearly marked), which
is placed over the Measurement board.
Measurement board (optional) Layout board example for the Measurement
board
Ordering code:
IAMS32K148
Not available in every Emulation Adapter or every MCU pin count.
