TASKING iSYSTEM NXP S32K148 Hardware User Manual page 18

Emulation adapter
Hide thumbs Also See for iSYSTEM NXP S32K148:
Table of Contents

Advertisement

Slot screw
The Slot screw (30mm) is used to fix the Conversion board to the Solder part. The setup be-
comes mechanically more robust.Screw the Conversion board to the Solder part first, before the
Emulation Adapter is attached on top and watch out not to break out the Solder part, e.g., if you
accidentally hit the Emulation Adapter from the side.
