- Page 1 NXP S32K148 EMULATION ADAPTER HARDWARE USER MANUAL V1.5, September 2024 www.tasking.com...
- Page 2 Use included power cord and power supply The enclosed power supply has been approved for use by TASKING. Please contact TASKING if you need to consider an alternative power.
-
Page 3: Table Of Contents
Operation ......................8 How to connect ..................... 8 Configuration ......................8 Connectors ......................13 Standalone operation ..................... 8 Mechanical information .................. 16 Emulation Adapter ....................16 Solder parts ......................16 Assembly ......................18 QFP Fixed ......................18 Accessories ....................20 www.tasking.com... -
Page 4: Introduction
Introduction NXP S32K148 Emulation Adapter is based on the 176-pin S32K148 superset device and provides full trace capability for the: · 48-pin · 64-pin · 100-pin · 144-pin device, where trace port is not available or lacks the full trace capability. -
Page 5: Package Content
Package content NXP S32K148 Emulation Adapter is delivered with all the components required for a standalone operation. Target adaptation parts for the Target board adaptation must be ordered separately. Power supply package NXP S32K148 Emulation Adapter Power converter Power adapter... -
Page 6: Options
QFP144 (0.5 mm) IEA-S32K148-TQ144 IA144TQ-SOLDER QFP Fixed Adaptation The adaptation is elivered with a slot screw, which can be used to achieve a more solid and stable fixing of the Conversion board and the Solder part. Conversion board Solder part www.tasking.com... -
Page 7: Measurement Board
MCU pins. It is delivered together with an Layout board (chip signals are clearly marked), which is placed over the Measurement board. Measurement board (optional) Layout board example for the Measurement board Ordering code: IAMS32K148 Not available in every Emulation Adapter or every MCU pin count. www.tasking.com... -
Page 8: Operation
(default 22pF populated) accordingly. Crystal socket Q1 is by default not populated (NP). Crystal socket Q1 schematics below: J6 - J15: Trace port configuration Soldered jumpers are placed by default to connect Arm CoreSight 20 connector trace signals to fast trace pins: www.tasking.com... - Page 9 Note that PTD16 can operate either as TRACE_CLK or TRACE_D2. Use of alternate ports decrease the performance of the trace interface since output drivers on these ports are slower. It's recommended to contact TASKING for assistance if the default trace configuration has to be changed.
- Page 10 TRACE DATA1 Port to PTD12 (alternative PTE4) · TRACE DATA2 Port to PTD11 (alternative PTD16) · TRACE DATA3 Port to PTD10 (alternative PTD15) P2: Power supply configuration Power supply of the Emulation Adapter is configured via the unshrouded 26-pin 2.54 mm header (P2). www.tasking.com...
- Page 11 Emulation Adapter. Only pins 1-2 and 3-4 must be bridged, but for the convenience and ease of use, all jumpers are set, except for pins 25-26. Pin 26 is the polarizer key pin preventing incorrect connection of the IEA-PS Power converter, when being plugged in. www.tasking.com...
- Page 12 Refer to the microcontroller documentation for more details about power voltage designations. J4 and J5: GND connection points In case a good ground connection is required, connection points bridge J4 and pin J5 provide easy access to the Emulation Adapter's GND potential. www.tasking.com...
-
Page 13: Connectors
Connectors P3, P4, P5 and P6 on the bottom side of the Emulation Adapter expose all emulation device signals toward the Conversion board, through which the Emulation Adapter adapts to different pin count packages. Standalone operation The Emulation Adapter is delivered with all components required for a Standalone operation. www.tasking.com... - Page 14 Be careful not to supply 5 V to the microcontroller power supply pin, which has declared a maximum voltage 3.3 V! Refer to the microcontroller documentation for detailed information on power supply. P3 connector on the Power Supply board External power supply requirements: Min Voltage Max Voltage Min Power 12 V Clock source www.tasking.com...
- Page 15 If the target’s crystal circuit microcontroller oscillator (if available) is not an adequate clock source, insert the appropriate crystal into the Q1 socket, replace the default 22pF C1 and C2 capacitors when necessary, and DIP switch DIP2 to position away from the white dot. www.tasking.com...
-
Page 16: Mechanical Information
In the case of soldering the Solder part manually, it’s highly recommended to prolong the solder pad E on the outer side (e.g., for 1.5–2 mm) during the PCB design. Note that without this modification, it’s very difficult to solder the Solder part manually. www.tasking.com... - Page 17 Recommended PCB footprint dimensions: Unit (mm) Ordering code IA48TQ-SOLDER 1.505 13.0 13.0 IA64ATQ-SOLDER 1.505 15.0 15.0 16.0 IA100TQ-SOLDER 16.5 1.125 17.0 17.0 2.15 19.55 19.55 IA144TQ-SOLDER 1.125 23.0 23.0 2.15 25.05 25.05 To view Emulation Adapter schematics, use the short link isystem.com/schematics. www.tasking.com...
-
Page 18: Assembly
Conversion board to the Solder part first, before the Emulation Adapter is attached on top and watch out not to break out the Solder part, e.g., if you accidentally hit the Emulation Adapter from the side. www.tasking.com... - Page 19 www.tasking.com...
-
Page 20: Accessories
Active Probe Parallel IC57801 / IC71801 Active Probe Debug IC70118 20-pin 1.27 mm Arm CoreSight Adapter IC50118-2 20-pin 1.27 mm CoreSight Debug Adapter IC50118-LV 20-pin 1.27 mm Low Voltage CoreSight Debug Adapter More information about our products via sales@tasking.com. www.tasking.com... - Page 21 Visit our website for: · Support - support.tasking.com · Getting started - isystem.com/start · Knowledge Base - kb.tasking.com www.tasking.com www.tasking.com...
