Measurement board
With the Measurement board you gain easy access to all MCU pins respectively, because mod-
ern targets do not have accessible all the MCU pins / connected signals to connect with a meas-
urement equipment (oscilloscope, logic analyzer).
The Measurement board is optional and connects between the Emulation Adapter and the Con-
version Board. It comes together with an applicable Layout board (black panel where all the CPU
signals are nicely marked) that matches your order. The black panel is placed over the Measure-
ment board.
Layout board example for the Measurement
Top view of the Measurement board
board
Not available in every Emulation Adapter or every MCU pin count.
