User Guide for the SIP-T42G IP Phone
Hardware component instructions of the T42G/S IP phone are:
Item
① LCD Screen
②
Power Indicator LED
③ Line Keys
Mute Key
Headset Key
④
Message Key
Redial Key
⑤ Speakerphone Key
⑥
Volume Key
⑦
Keypad
⑧
⑨
Soft Keys
⑩
Speaker
⑪ Hookswitch Tab
⑫
Hookswitch
2
Shows information about calls, messages, soft keys,
time, date and other relevant data:
• Call information—caller ID, call duration
• Icons (for example,
• Missed call text or second incoming caller information
• Prompt text (for example, "Saving config file!")
• Time and date
Indicates phone power and some feature statuses.
Use these keys to activate up to twelve accounts and
assign various features.
Toggles and indicates mute feature.
Toggles and indicates the headset mode.
Accesses voice mails.
Redials a previously dialed number.
Toggles the hands-free speakerphone mode.
Adjusts the volume of the handset, headset, speaker,
and ringer.
Provides the digits, letters, and special characters in
context-sensitive applications.
Scroll through the displayed information.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
Label automatically to identity their context-sensitive
features.
Provides ringer and hands-free (speakerphone) audio
output.
Secures the handset in the handset cradle when the IP
phone is mounted vertically. For more information on
how to adjust the hookswitch tab, refer to
Mount Quick Installation Guide for T4X IP Phones
Picking up the handset from the handset cradle, the
hookswitch bounces and the phone connects to the line,
laying the handset down on the handset cradle, the
phone disconnects from the line.
Description
)
Tadiran Wall
.
