Tools Required - Modular Closets MUDROOM Assembly And Installation Instructions Manual

INSTALLATION INSTRUCTIONS
1B
R
S
T
U
V
W
X
1C
1.1
Lay parts out on a protective surface to prevent
damage. Tip: Spread out the cardboard packaging
to use as a protective surface.
1.2
Inventory parts against the Parts List. Make sure
all parts are present before proceeding.
ASSEMBLY AND
MUDROOM
Z AA
PARTS LIST
R
Drawer Panel, Front (Qty 1)
S
Drawer Panel, Rear Qty (1)
T
Drawer Panel, Side (Qty 2)
U
Drawer Front (Qty 1)
V
Drawer Bottom (Qty 1)
W
Drawer Slide (Qty 2)
X
Shelf Slide (Qty 2)
Y
Drawer Handle (Qty 1)
Z
Euro Screw, 5/8" (Qty 2)
AA
Screw, 5/8" (Qty 2)
BB
Screw, 1" (Qty 18)
CC
Screw, 1.5" (Qty 6)
DD
Wood Dowel, 6mm (Qty 24)

TOOLS REQUIRED

(not included unless noted)
Level
Stud Finder
Drill, 5/32" bit size
Phillips Screwdriver
Y
CC
BB
DD
