ASSEMBLY AND
INSTALLATION INSTRUCTIONS
TALL HANGING UNIT
1A
BOX 1
A
B
A
Left Side Panel
B
Right Side Panel
1B
1.1
Lay parts out on a protective surface
to prevent damage. Tip: Spread out
the cardboard packaging to use as a
protective surface.
1.2
Inventory parts against the Parts List.
Make sure all parts are present before
proceeding.

PARTS LIST

BOX 2
C
D
E
G
C
Rear Hanging Cleat (Qty 2)
D
Set Shelf (Qty 2)
E
Hanging Rod
F
Rod Bracket (Qty 2)
G
Cam Post (Qty 12)

TOOLS REQUIRED

(not included unless noted)
Level
Stud Finder
Drill, 3/32" bit size
Phillips Screwdriver
Drill Bit, Square #2

FINISHED EDGE

FINISHED EDGE
H
I
H
Camlock (Qty 12)
I
Screw, 5/8" (Qty 2)
J
Screw, Square Drive,
2.5" (Qty 4)
F
J
