INSTALLATION INSTRUCTIONS
11
K
C
K
11.1
Insert Camlocks (K) in holes in Set Shelves (C) and Cleats (I) with arrow pointing toward Cam Post opening.
Be sure Camlocks engage Cam Posts, and are fully seated in Shelf and Cleats.
11.2
Tighten Camlocks (K) clockwise to lock.
ASSEMBLY AND
MUDROOM
ARROW TOWARD
CAM POST OPENING
K
K
I
K
K
K
I
K
K
K
K
