INSTALLATION INSTRUCTIONS
16
TYPICAL HOOK
INSTALLATION
16.1
Installation of Hooks (O, P) is optional. If desired, install Hooks at one or more of the following lodations:
- Install one or two 3-Prong Hooks (O) on Upper Left Side Panel (A). (Dimples on the vertical centerline of the
Side Panel show the recommended placement for the Hooks.)
- Install one 2-Prong Hook (P) at the desired location on Cleat (I) below Upper Set Shelf (C).
16.2
Drill two pilot holes for each Hook (O, P) at the desired mounting location(s), then secure each Hook with two
0.75" Screws (Q).
Note: In cases where Adjustable Shelf (D) is installed (see step 15), install Hooks (O, P) on Upper Left Side Panel (A)
and/or Upper Right Side Panel (B) at locations below the Shelf.
ASSEMBLY AND
MUDROOM
O
Q
Q
A
C
O
