ASSEMBLY AND
INSTALLATION INSTRUCTIONS
DRAWER KITS
1
A
C
D
A
Drawer (Qty 2)
B
Drawer Front (Qty 2)
C
Drawer Slide (Qty 4)
D
Shelf Slide (Qty 4)
E
Drawer Knob (Qty 2)
NOTE: Each set of Drawer Slides (C) and Shelf Slides (D) are shipped assembled. To separate, lift the plastic
catch on the Drawer SLide and pull the Slide out of the Shelf Slide.
1.1
Lay parts out on a protective surface to prevent damage. Tip: Spread out the cardboard packaging to
use as a protective surface.
1.2
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
E

PARTS LIST

F
Screw, 5/8" (Qty 8)
G
Screw, 5/8" (Qty 8)
H
Screw, 1.0" (Qty 4)
I
Screw, 1.5" (Qty 2)
B
F G H I

TOOLS REQUIRED

(not included)
Drill, 5/32" bit size
Phillips Screwdriver
