ASSEMBLY AND
INSTALLATION INSTRUCTIONS
SHORT TOWER
1A
BOX 1
A
A
Left Side Panel (Qty 1)
B
Right Side Panel (Qty 1)
BOX 4 Leg Extension Kit (Optional)
F
C
FINISHED EDGE
H
C
Rear Hanging Cleat (Qty 1)
F
Left Leg Extension (Qty 1)
G
Right Leg Extension (Qty 1)
H
Cam Post (Qty 2)
I
Camlock (Qty 2)
K
Wood Dowels (Qty 4)
PARTS LIST
B
G
K
I
BOX 2
C
FINISHED EDGE
D
FINISHED EDGE
C
Rear Hanging Cleat (Qty 2)
D
Set Shelf (Qty 2)
H
Cam Post (Qty 12)
I
Camlock (Qty 12)
L
Screw, Square Drive, 2.5" (Qty 4)
BOX 3
E
FINISHED EDGE
E
Adjustable Shelf (Qty 2)
J
Shelf Pins (Qty 8)
TOOLS REQUIRED
(not included unless noted)
Level
Stud Finder
Drill, 3/32" bit size
Phillips Screwdriver
Drill Bit, Square,
#2
H
I
L
J
