INSTALLATION INSTRUCTIONS
2
2.1 Install one Cam Post (J) into each of the 6 holes on Bench Top Shelf (G). Tighten until Cam Posts are seated
against Top Shelf.
3
3.1 Install one Cam Post (J) into each of the 10 holes on Bench Left Side Panel (E) and Bench Right Side Panel (F).
Tighten until Cam Posts are seated against Side Panels.
ASSEMBLY AND
MUDROOM
J
J
J
J
F
J J
J
J
J
J
J
J
J
J
G
J
J
E
