TRANSPORT AND STORAGE

0026
/10 = rated power P
Frequency
5 5 = 50 Hz
6 = 60 Hz
40
Key for rated voltage
Additional electrical equipment
O = with bare cable end
P/MS
P = with plug
P/MS = with plug and switchgear

3.7. Scope of delivery

• Sewage lifting unit ready for connection with
switchgear, 4 m cable and plug
• 1x inlet seal DN 100 for plastic pipe (Ø 110 mm)
• 1x keyhole saw (Ø 124 mm) for inlet DN 100
• 1x collar for inlet connection DN 50 (for separate
intake or for the suction line of the diaphragm
hand pump)
• 1x collar for ventilation connection DN 70
• 1x flange connector DN 80/100 with flat gasket,
collar, pipe clamps, bolts and nuts for connecting
the discharge pipeline DN 100
• 1 set of fixation material (2 mounting brackets,
screws, wall plugs, washers)
• 6x (FIT L1) or 8x (FIT L2) damming protective
strips for insulation of structure-borne noise
• Installation and operating instructions for the
lifting units
• Installation and operating instructions for the
switchgear

3.8. Accessories (optionally available)

• On pressure side:
• Flange connectors DN 80, DN 100, for connec-
tion of the gate valve on the pressure side to
the pressure pipe
• Gate valve DN 80 made of cast iron
• On intake side:
• DN 150 intake set comprising keyhole saw
(Ø 175 mm) and inlet seal
• Gate valves DN 100 and DN 150 made of PVC
• Inlet seal DN 100
• General:
• Diaphragm hand pump with R1½ connection
(without hose)
• 3-way cock for switching over to the manual
suctioning from the pump sump/tank
• Alarm switchgear
• Rechargeable battery (NiMH, 9 V, 200 mAh)
• Horn 230 V, 50 Hz
• Flash light 230 V, 50 Hz
• Signal lamp 230 V, 50 Hz
4. Transport and storage
DANGER due to poisonous substances!
Lifting units that pump fluids that are harmful
to health must be decontaminated before any
other work is performed! Otherwise, there
is a risk of fatal injury! Wear the necessary
physical protection equipment!
Installation and operating instructions Wilo-RexaLift FIT L
in kW
2

4.1. Delivery

On delivery, check immediately that the ship-
ment is complete and undamaged. If any parts
are damaged or missing, the transport company
or the manufacturer must be notified on the day
of delivery. Claims made after this date cannot be
recognised. Damage to parts must be noted on
the delivery or freight documentation.

4.2. Transport

Only the appropriate and approved fastening de-
vices, transportation and lifting gear may be used.
It must have a sufficient bearing capacity and
safe working load in order for the lifting unit to
be transported safely. When the chains are used,
they must be secured against slipping.
The personnel must be qualified to carry out this
work, and must comply with all nationally appli-
cable safety regulations during the work.
The lifting units are supplied by the manufacturer
or supplier in suitable packaging. This normally
precludes the possibility of damage occurring
during transport and storage. The packaging
should be stored in a safe place for reuse if the
product is frequently used at different locations.

4.3. Storage

Newly delivered lifting units are prepared in such
a way that they can be stored for at least 1 year.
For temporary storage, the lifting units must be
thoroughly rinsed with clean water before storage
in order to prevent encrustations and deposits
building up in the collection reservoir, on the level
control and the pump hydraulics.
DANGER due to poisonous substances!
Flushing through the lifting unit contami-
nates the flushing water with faeces. Risk of
fatal injury due to contact with fluid that is
harmful to health! Always wear the necessary
physical protection equipment and channel
the flushing water into the sewer system at
suitable points!
The following should be taken into consideration
for storage:
• Place the lifting unit securely on a firm bearing
surface, and secure it to prevent tipping over and
sliding. Lifting units are stored horizontally.
• Lifting units can be stored at temperatures down
to ‑15 °C if completely emptied. The store room
must be dry. We recommend a frost-protected
room for storage with a temperature between
5 °C and 25 °C.
• The lifting unit is not allowed to be stored in
rooms in which welding work is carried out, be-
cause the resulting gases or radiation can damage
the elastomer components.
• All connections must be sealed securely to pre-
vent contamination getting in.
• All power supply cables must be protected
against kinking, damage and moisture ingress.
Furthermore, mounted plugs and switchgear
must also be protected against moisture ingress.
