- Page 1 COR 2-3MHI(E)***/SCE Installation and operating instructions 29992313 COR 2MHI202/SCe_EM 29992329 COR 3MHI202/SCe_EM 29992370 COR 2MHI202/SCe_EM_T260AB 29992314 COR 2MHI203/SCe_EM 29992330 COR 3MHI203/SCe_EM 29992371 COR 2MHI203/SCe_EM_T260AB 29992315 COR 2MHI204/SCe_EM 29992331 COR 3MHI204/SCe_EM 29992372 COR 2MHI204/SCe_EM_T260AB 29992316 COR 2MHI205/SCe_EM 29992332 COR 3MHI205/SCe_EM 29992373 COR 2MHI205/SCe_EM_T260AB 29992317 COR 2MHI206/SCe_EM...
-
Page 2: Table Of Contents
Contents Page 1) General 2) Safety Instructions 2.1 Symbols and Signals 2.2 Modification and Spares 3) Transport and Storage 4) Product Description 4.1 SCe Controller - General 4.1.2 Operating Features 4.2 MHIE SCe-DM (Three Phase) 4.3 MHI SCe-EM (Single Phase) 5) Installation and Operation 5.1 Foundation 5.2 Hydraulic Connections... -
Page 3: General
Using a the booster set and any risks associated. For more programmable set point and a 4-20mA pressure information on training please contact Wilo Ph: 01283 523 000 transducer on the discharge manifold. When... -
Page 4: Mhie Sce-Dm (Three Phase)
For the set to function. Any changes could affect the information contact service.uk@wilo.com or Ph: performance or damage the booster 01283 523 0000 5 Installation and operation 5.4 Electrical Connections (Fig2-3) -
Page 5: Low Water Cut Out Switch
Wilo UK service installation conditions. This should be done in department. Checks should be made on the... -
Page 6: Warranty
7 Warranty WILO reserve the right to inspect an installation to verify that the equipment has been installed in accordance with the written instructions. The full warranty document is downloadable at www.wilo. co.uk click on local information then downloads. Before requesting a site visit, the following information must be available to the service team: •... - Page 7 Table 2 SCe-DM Drive Fault Codes Code Response Restart Faults Remedies Time E001 Immediately Pump is in overload condition, Density and/or viscosity of the conveyed defective liquid is too high Pump is obstructed by particles Dismantle the pump and replace or clean the defective components E004 300s...
-
Page 8: Fig 1 Pump Vents
Figure 1 Pump Vents Figure 2 DM Electrical Connections* * For detailed wiring diagrams see the elctrical drawings refer to the drawings in the customer pack Figure 3 EM Electrical Connections* * For detailed wiring diagrams see the elctrical drawings refer to the drawings in the customer pack... -
Page 9: Fig 4 Low Water Cut Out Switch Setting
Figure 4 Low Water Cut Out Switch Setting Figure 5 General Arrangement... -
Page 13: Certificate Of Conformity
EN61000-6-3:2007 +A1:2011 EN61000-6-2:2005 If the above mentioned series are technically modified without our approval, this declaration shall no longer be applicable Authorized representative for the completion of the technical documentation: WILO UK Centrum 100 Lee Tebbatt Second Avenue Burton-Upon-Trent Managing Director...
