Goodrive800 Pro Series Regenerative Rectifier Hardware Manual
No.
Ethernet interface 1 for
A
PROFINET communication
Ethernet interface 2 for
B
PROFINET communication
PROFINET communication
C
status indicator
PROFINET communication
D
card interface pins
202308 (V1.1)
Name
The PROFINET communication card uses two standard RJ45
interfaces, which do not distinguish the direction and can be
swappable.
Pin
1
2
3
4
5
6
7
8
Used to display faults
LED1
LED2
(Bus status
indicator)
LED3
(System fault
indicator)
LED4
(Slave ready
indicator)
LED5
(Maintenance
status
indicator)
Used for hard connection with the main control box
Description
Two standard RJ45 interfaces
Function
TX+ Transmit Data+
TX- Transmit Data-
RX+ Receive Data+
n/c Not connected
n/c Not connected
RX- Receive Data-
n/c Not connected
n/c Not connected
LED Color Status
Green
On
Blinking
Red
Off
On
Red
Off
On
Blinking TPS-1 waits for MCU initialization.
Green
Off
Green
Description
Description
3.3V power indicator
No network connection
The network connection to the
PROFINET controller is OK, but the
communication is
established.
Communication with
PROFINET controller has been
established.
PROFINET diagnosis exists.
No PROFINET diagnosis.
TPS-1 protocol stack has started.
TPS-1 protocol stack does not
start.
Manufacturer-specific, depending
on the characteristics of the
device
Expansion card
not
the
