Goodrive800 Pro Series Regenerative Rectifier Hardware Manual
2.6.2 Layout of L+2*A8
The following figure shows the frame layout of L+2*A8.
No.
1
2
3
4
5
202308 (V1.1)
Figure 2-8 Structure of regenerated rectifier frame (L+2*A8)
1
4
5
Regenerative rectifier filter unit
Name
Cabinet
Regenerative rectifier unit
Regenerative rectifier unit
Channel steel base
Product overview
2
3
11
