Goodrive800 Pro Series Regenerative Rectifier Hardware Manual
No.
15
16
17
Note: A 40X40 sealing sponge must be used at the position corresponding to the air baffle in the
front/back door panel, which prevents air duct reflow.
3.3.6.3 Layout and mounting for L+2*A8
Figure 3-14 shows the 850mm-wide cabinet layout for L+2*A8.
No.
1
2
3
4
5
202308 (V1.1)
Front sealing sponge
Back sealing sponge
Left protective plate
Figure 3-14 Cabinet layout for L+2*A8
Regenerative rectifier unit
Regenerative rectifier filter unit
Regenerative rectifier unit
Name
Name
DC fuse
AC fuse
Mechanical installation
1
2
3
4
5
25
