Goodrive800 Pro Series Regenerative Rectifier Hardware Manual
Thank you for choosing INVT Goodrive800 Pro series engineering variable-frequency drive (VFD).
For ease of use, read the manual carefully before using Goodrive800 Pro series product.
As an upgrade product of Goodrive800 series engineering VFD, Goodrive800 Pro series engineering VFD
inherits the high reliability feature of Goodrive800 platform but optimizes the upgrade, structure, and
components, achieving unit modularization, flexible cabinet configuration, more compact structure, easier
installation and maintenance, and optimum protection.
Excellent speed and torque control performance

Modular design, as flexible as building blocks, which makes the project integration simple and efficient

Long-life component selection and fast fault recovery design to ensure efficient process control

Ergonomic design to make installation and maintenance easier

Enriched expansion capability to support various protection options

Goodrive800 Pro series engineering VFD can be widely used in:
Metallurgy: Such as high-speed wire rod and hot strip rolling equipment, wide and thick plate equipment,
cold rolling equipment, pickling lines, annealing lines, galvanizing line, color coating lines, non-ferrous
metal alloy manufacturing equipment, and non-ferrous metal rolling equipment
Petroleum: All-electric oil drilling rigs, large well repair machines, large oil machinery and equipment
electric-drive power transformation, oilfield water injection equipment and other heavy oil equipment
Paper making: Paper making joint equipment, including flow box, net section, press section, drying section,
sizing, hard calendering, coating, super calender, rewinder and other continuous production lines
Port and other large lifting equipment: Such as shore-side container overhead cranes, tire-type (orbital)
container gantry cranes, grab unloaders, grab gantry cranes, large shipbuilding gantry cranes, and large
metallurgical casting cranes
Others: Such as unit test benches, military equipment, oil and gas transmission, and mining transmission
equipment
Goodrive800-81 series is the regenerative rectifier unit of Goodrive800 Pro series. If not otherwise specified,
the regenerative rectifier in this manual refers to the regenerative rectifier unit of Goodrive800 Pro series,
that is, Goodrive800-81 series product. The rated power of a single unit is 423kW–1027kW, and the max.
parallel power can be 5726kW. The regenerative rectifier consists of regenerative rectifier filter unit and
regenerative rectifier unit. It is compact in structure and easy to integrate and maintain, reducing cabinet
footprint.
This manual is Goodrive800 Pro series regenerative rectifier hardware manual, presenting safety
precautions, product information, mechanical and electrical installation, and precautions related to daily
maintenance. Read through this manual carefully before installation to ensure the VFD is installed and
operated in a proper manner to give full play to its excellent performance and powerful functions. If you
have any question about the function and performance of the product, please consult our technical support.
If the product is ultimately used for military affairs or weapon manufacture, comply with the export control
regulations in the Foreign Trade Law of the People's Republic of China and complete related formalities.
To continuously improve the performance of the product to meet higher application requirements, we
reserve the right to continuously improve the product and accordingly the product manual, which may be
made without prior notice. We have the final interpretation of the manual content.
202308 (V1.1)
