adjacent motion detections. The alarm will remain active for the
duration of the holding time. If there is motion detected while the
alarm is still ongoing, it will be considered as continuous
movement; otherwise, it will be considered as a single motion.
• Trigger SD Card Snapshot: Enable to allow the camera to take a still
image when the alarm is triggered (SD card required).
• Trigger SD Card Recording: Enable to allow the camera to record
video to the SD card when the alarm is triggered (SD Card required).
•
Trigger Email: Enable to allow the camera to use SMTP to send e-mail
notifications when the alarm is triggered. Refer to
for more information.
• Trigger FTP: Enable to allow the camera to send snapshots and
recordings to an external FTP server when the alarm is triggered.
Refer to Section
Motion Area and Sensitivity
Set the motion detection area and the detection sensitivity.
Click the "Area and Sensitivity" tab to go to the interface as shown below.
• Sensitivity: Move the "Sensitivity" slider to set the detection
sensitivity. A higher sensitivity value means that the motion alarm
will be triggered more easily.
• Draw Area: Select the "Add" toggle then click "Draw". Draw the
motion detection area for the Motion Alarm in the grid. Highlighted
squares in the grid indicate active detection areas. Select the "Erase"
toggle to selected and clear motion detection areas from the grid.
Click the "Save" to save the settings.

5.4.2 Other Alarms

SD Card Full
5.2.10 FTP
for more information.
40
Section 5.2.9 SMTP
