NOTE: The GUI display may differ by camera models.
Icon
AUDIO
ON/OFF
SNAPSHOT
START
RECORD
D-ZOOM IN
D-ZOOM OUT
ZOOM/FOCUS
IVA EVENT
INFO
NOTE: Line Crossing and Perimeter Intrusion cannot be enabled at the
same time.
Smart alarm indicators will flash only when the camera supports the functions
and if events are enabled.
*Plug-in free live view: local recording is not supported.
Click the ZOOM/FOCUS button to show the AZ control panel. This is available
on supported models.
Description
Enable/disable audio (on
supported models)
Snapshot
Start/stop local recording
(on supported models)
Digital zoom in the live
Digital zoom out the live
AZ control (only available
for
the
model
motorized zoom lens)
Event
rule
information
display
Icon
with
8
Description
SD card recording indicator
Motion alarm (on supported
models)
Color abnormal
Abnormal clarity
Scene change
Line crossing
Perimeter Intrusion
