To configure FTP settings:
1. Click the "Add" button to configure FTP server information for the
following:
• Server Name: Enter the name of the FTP server.
• Server Address: Enter the IP address or domain name of the FTP
server.
• Upload Path: Enter the folder directory where files will be
uploaded.
•
Port: Enter the port number of the FTP server.
• Username and Password: Enter the username and password that
are used to log in to the FTP server.
2. Click "OK" to close the configuration window then click the "Save"
button to apply the settings. When configuring event settings for
intrusion, line crossing, etc., you can then enable "Trigger FTP" to
assign the FTP connection.
Rule of FTP storage path:
Example FTP file path：
Event name table:
/device MAC address/event type/date/time/
\00-18-ae-a8-da-2a\VFD\2021-01-09\14\
File Name
MOTION
SENSOR
TRIPWIRE
PERIMETER
AVD
SDFULL
Event Type
Motion Detection
Sensor Alarm
Line Crossing Detection
Region Intrusion Detection
Video Exception
SD Full
