Bullet Camera DWC-B6563DIR DWC-B6563DIR DWC-B6563DIR DWC-B6563DIR DWC-B6563TIR550 DWC-B6563TIR550 DWC-B6563TIR550 DWC-B6563TIR550 ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference. 12162013...
Page 2
PRECAUTIONS Do not open or modify. Do not open the case except during maintenence and installation, for it may be dangerous and can cause damages. Do not put objects into the unit. Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages.
Table of Contents TABLE OF CONTENTS Introduction Features Parts and Descriptions Dimensions Installation Inside the Box Mount Installation Instructions Connecting to Monitors Control Board Adjusting the Camera Angle Module OSD Menu 13-24 Troubleshooting Warranty Information 26-27 Specifications 28-29...
Page 4
720 TV Lines [B/W], 700 TV Lines [Color] 2.8~12mm Varifocal Auto Iris Lens [DWC-B6563DIR] 5~50mm Long Range Varifocal Auto Iris Lens [DWC-B6563TIR550] 100ft Range IR with Intelligent Camera Sync, Smart IR [DWC-B6563DIR] 150ft Range IR with Intelligent Camera Sync, Smart IR [DWC-B6563TIR550] Electronic Day & Night [DWC-B6563DIR] TDN (True Day &...
PARTS & DESCRIPTION* IR Module Mounting Bracket Front Case Camera Module OSD Joystick Controller Sunshield Adjusting Screws Sunshiled Cover Set Screw...
User Manual Secondary Video-BNC Cable Mounting Template L-Key 4 Machine Screws and 4 Dry Wall Anchors Bullet Camera DWC-B6563DIR DWC-B6563DIR DWC-B6563DIR DWC-B6563DIR ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference.
INSTALLATION INSTRUCTIONS* 1. Using the mounting template or your own camera, mark and drill the necessary holes to mount the bracket to a wall or ceiling. 2. Pull all necessary wires through and make the proper connections. 3. Use the four (4) mounting screws to install the camera on the wall or ceiling.
CONNECTING TO MONITORS* Use the diagram below to connect to a Monitor or CRT Monitor properly. 12VDC/24VAC CCTV Monitor Left Right Down Second Video Output Monitor Power Connection - 12VDC/24VAC Dual Voltage (Auto Polarity Detection and Protection) All cameras are equipped with a second video output for on-site configuration.
CONTROL BOARD* Secondary Connector: Video Output Connector for On-Site Configuration Joystick: Controls the OSD menu. Remove the camera’s lens cover by rotating it counter-clockwise. Use the Joystick to control the camera’s OSD options.
MODULE OSD MENU* EXPOSURE COLOR DAY & NIGHT FUNCTION LENS WB BAL. D&N MODE MIRROR MANUAL / DC ATW / MANUAL / PUSHLOCK AUTO / COLOR / B&W OFF / ON BACKLIGHT CONTROL SHARPNESS COLOR GAIN OFF / BLC / HME AUTO / EXTERN 0 ~ 20 0~20...
Page 14
EXPOSURE LENS Manual mode supports the fixed board lens or the Manual manual iris lens. DC mode supports the auto-iris varifocal lens. NOTE: Both MANUAL and DC mode have FOCUS SET. You can adjust the focus by finding the highest number on the FOCUS SET.
Page 15
EXPOSURE BACKLIGHT BACK LIGHT COMPENSATION If BLC is selected, adjust the following options in the submenu: - LEVEL: Set the BLC level from the available options: LOW/ MIDDLE/ HIGH) - DISPLAY: Selet to show or hide the BLC mask. - POSITION: Set the BLC masks’ size and position. TOP: Set level from 0~54.
Page 16
EXPOSURE DYNAMIC RANGE COMPRESSOR DRC enables dark spots in images to become more visible without overexposing the bright spots to create one perfect image. - DEFOG: AUTO / Manual: If AUTO is selected, the WDR and DRC levels will be set automatically based on the environment.
Page 17
COLOR WB MODE Auto Tracking White Balance Control mode compensates for color temperature changes between 2500K and 9500K. Pushlock is to fix the white balance based on the lighting. PUSHLOCK Users can control the white balance manually by changing RED GAIN and BLUE MANUAL GAIN (see below).
Page 18
DAY & NIGHT D&N MODE AUTO / In AUTO mode, the camera switches between day and night automatically depending COLOR / on light level. If COLOR is selected, the camera always stays in day/color mode. B&W If B&W is selected, camera always stays in night/B&W mode. If AUTO is selected, please define the following settings: CONTROL: AUTO/EXT.
Page 19
FUNCTION MIRROR Reflects the camera horizontally. MIRROR Mirror OFF Mirror ON SHARPNESS Sets the image sharpness. The higher the number, the sharper the image. 0 ~ 30 GAMMA Select the desired gamma level. 0.45 is default setting. 0.35 ~ 0.7 POSI / NEGATIVE If NEGATIVE is enabled, the camera’s image OFF / ON...
Page 20
MOTION The camera can detect the movement and display an alarm on the screen when movement is detected. MOTION Select to enable or disable the camera’s motion detection. If ON is selected: OFF / ON SENSITIV. Sensitivity level of the motion detection is adjustable. Motion Detection will be more 0 ~ 30 sensitive at a higher number.
Page 21
PRIVACY You can hide some parts of the screen for privacy masking. A total of 8 different privacy masking zones are available. MASK COLOR Privacy zones can be set with eight different colors-Gray-1, Gray-2, Gray-3, Gray-4, White, Yellow, Green, Blue, Red, Cyan, and Magenta.
Page 22
SETUP TITLE If ON is selected, you can display the camera title on the screen. If enabled, OFF / ON manually enter the camera’s display name using the joystick controller. INTERNAL SYNC. Select whether the camera syncronizes internally or using Line Lock. INT/ COMMUNICATION The Communications settings allow you to setup the camera’s ID, Baudrate, Protocol,...
Page 23
SETUP LANGUAGE The camera supports the following languages: ENGLISH. FONT COLOR The following colors are available for the OSD menu: BLUE, GREEN, CYAN, RED, MAGENTA, YELLOW, BLACK, and GRAY. SPECIAL OLPF: Select the filter that you use from BLUE/RED and PASS, then reboot the camera to use.
Page 24
EXIT EXIT SAVE Exit the OSD menu after saving the recent changes. RESTORE Exit the OSD menu without saving recent changes. INITIAL Exit the OSD menu after resetting the camera to factory default.
TROUBLESHOOTING Before sending your camera for repair, check the following or contact our technical specialist. FOR NO VIDEO Check the coaxial cable and make sure it is connected securely. Check the lens’ iris adjustment at the camera’s OSD menu. Check the power supply and make sure the camera has the proper voltage and current.
WARRANTY INFORMATION* Digital Watchdog (referred to as “the Warrantor”) warrants the Digital Watchdog Camera against defects in materials or workmanship as follows: LABOR: For the initial five (5) years and one (1) year on IR LED from the original purchase date, if the camera is determined to be defective, the Warrantor will repair or replace the unit with a new or refurbished product at its option at no charge.
Page 27
LIMITS & EXCLUSIONS* There are no express warranties except as listed. The warrantor will not be liable for incidental or consequential damages (including damage to recording media without limitation) resulting from the use of these products or arising out of any breach of the warranty. All express and implied warranties, including the warranties of merchantability and fitness for particular purpose, are limited to the applicable warranty period set forth above.
CVBS: 1.0Vp-p / 75 Ω LENS Focal Length 2.8~12mm [DWC-B6563DIR] 5~50mm [DWC-B6563TIR550] Lens Type Varifocal Auto Iris Lens IR Distance 100ft Range IR [DWC-B6563DIR] 150ft Range IR [DWC-B6563TIR550] OPERATIONAL Shutter Speed 1/60s~1/120000s Backlight OFF / ON Star-Light X2 ~ X512...
Page 29
AC24V: 1.8W, 75 mA, LED On: 3.2W, 133mA B6563TIR550: DC12V: 1.8W, 150mA, LED On: 4.2W, 350mA AC24V: 1.8W, 785mA, LED On: 3.9W, 162.5mA MECHANICAL Housing Material Aluminum Dimensions 234.5 x 82.2 mm (9.23 X 3.23 in) Weight 1.7 lbs (DWC-B6563DIR) 2.05 lbs (DWC-B6563TIR550)
