AXIS Q6075-S PTZ Network Camera
Configure your device
Zoom in on a specific area automatically with gatekeeper
This example explains how to use the gatekeeper functionality to make the camera zoom in automatically on the license plate of a
car that passes through a gate. When the car has passed, the camera zooms out to the home position.
Create the preset positions:
1. Go to PTZ > Preset positions.
2. Create the home position that includes the entrance of the gate.
3. Create the zoomed-in preset position so that it covers the area in the image where you assume that the license plate
will appear.
Create a motion detection profile:
1. Go to Apps and start and open AXIS Video Motion Detection.
2. Create a profile that covers the entrance of the gate and then save the profile.
Set up motion detection:
1. Go to Apps and start and open AXIS Object Analytics.
2. Create an object in area scenario for vehicles, with an include area that covers the entrance of the gate.
Create a rule:
1. Go to System > Events and add a rule.
2. Name the rule "Gatekeeper".
3. In the list of conditions, under Application, select the Object Analytics scenario.
4. In the list of conditions, under Application, select VMD4.
5. In the list of actions, under Preset positions, select Go to preset position.
6. Select a Video channel.
7. Select the Preset position.
8. To make the camera wait a while before it returns to the home position, set a time for Home timeout.
9. Click Save.
Set up the intrusion alarm
Important
To set up an intrusion alarm you need the AXIS Dome Intrusion Switch C.
With a dome intrusion switch mounted inside the camera, you can receive a notification if someone removes the camera dome.
Use the intrusion alarm switch to, for example, send a notification if someone opens the camera housing.
Before you start
•
Connect the intrusion alarm switch to pin 1 (ground) and pin 3 (digital input) of the camera's I/O connector.
•
Connect the intrusion alarm switch to pin 1 (ground) and pin 3 (digital I/O) of the camera's I/O connector.
Configure the input port
1. Go to System > Accessories > I/O ports.
22
