AXIS Q6075-S PTZ Network Camera
Configure your device
3. Go to System > Events.
4. Create a new rule.
5. Select the Condition that must be met to trigger the camera to start recording. It can, for example, be a time schedule or
motion detection.
6. In the list of actions, select Record video. Select a storage space. Select a stream profile or create a new. Also set the
Prebuffer and Postbuffer as required.
7. Save the rule.
8. Create a second rule and select the same Condition as in the first rule.
9. In the list of actions, select Toggle I/O while the rule is active, and then select the port the AXIS I/O Indication LED is
connected to. Set the state to Active.
10. Save the rule.
Other scenarios where AXIS I/O Indication LED can be used are for example:
•
Configure the LED to turn on when the camera starts, to indicate the presence of the camera. Select System ready as
a condition.
•
Configure the LED to turn on when live stream is active to indicate that a person or a program is accessing a stream from
the camera. Select Live stream accessed as a condition.
Record video when the camera detects impact
Shock detection allows the camera to detect tampering caused by vibrations or shock. Vibrations due to the environment or to an
object can trigger an action depending on the shock sensitivity range, which can be set from 0 to 100. In this scenario, someone is
throwing rocks at the camera after hours and you would like to get a video clip of the event.
Turn on shock detection:
1. Go to System > Detectors > Shock detection.
2. Turn on shock detection, and adjust the shock sensitivity.
Create a rule:
3. Go to System > Events > Rules and add a rule.
4. Type a name for the rule.
5. In the list of conditions, under Device status, select Shock detected.
6. Click + to add a second condition.
7. In the list of conditions, under Scheduled and recurring, select Schedule.
8. In the list of schedules, select After hours .
9. In the list of actions, under Recordings, select Record video while the rule is active.
10. Select where to save the recordings.
11. Select a Camera.
12. Set the prebuffer time to 5 seconds.
13. Set the postbuffer time to 50 seconds.
14. Click Save.
21
