Assembly instructions

Step 1
Insert the Guide rods (18) into the
holes on the Rear stabilizer (4).
Align the holes.
Attach rear of the base frame (1) to
the Rear stabilizer (4). Fix using M10
, Φ10 Washers (61)
×65bolts( 49) × 2
(63)
and M10 nuts
× 2
.
Note-The two M10X60 bolts(50)should be put
through the holison Guide Rods(18)as well.
Fully tighten bolts.
Slide 61mm Rubber bumpers (29)
down onto Guide rods (18).
× × 4
1
1
7
29
18
21
49
29
18
61 63
4
21
