Parts Listing
Sensor Plus™ End Control Part No. 42343
Item Description
1 Danger Decal
2 Tube support
3 Junction box
4 Switch mount bracket
5 1/2" conduit connector
6 Top cover
7 Top body cover
8 Anchor plate
9 Cord assembly
10 1/2" connector
11 Decal
12 Insulator
13 Control body
14 Stub tube weldment
15 Drive block
16 Drive tube weldment
17 Skth screw
18 Flat washer
*19 Adapter Plate
*20 Sensor Plus Level Switch 48579
* These Items may be ordered as a kit Part No. 43711
50
Part No. Item Description
2527-9 *21 Sensor retainer
27891 *22 Plastic adapter plate
42627-8 *23 Black tubing
43815 *24 1/2" Liquid tight connector 23779
26980 25 ----
27941 26 Drive rivet
27942 27 Drop tube weldment
4188 28 Feeder pan plastic
4999-100 29 Feed level ring
24685 30 Feed level tube
2529-734 Feed level tube
2976 31 Pan support
27889 Pan support swing down
27900 32 Pan shield
4642 33 Bottom cover
47584 34 1/2" liquid tight connector
5083-8 35 90 Deg, 1/2" connector
1484
43813
Adult Turkey Feeder, MODEL ATF™
Part No.
46728
43819
14454-10
----
4200
4180
29000
29320
4194
4341
4199
24274
4191
27893
26982-1
23810
MF232Q
