Toptech MultiLoad II Mobile Installation Manual page 32

Chapter 6 – MutliLoad Configuration
Parameter
IP Mask
IP Gateway
IP Host
Socket Port
Com 0 Port
Com 1 Port
Com 2 Port
HTTP Port
After enabling the network and rebooting the MultiLoad II, the two network activity lights next to the Ethernet
connection should become active indicating network activity and link status. The Boot Screen will display as:
For security reasons, IP Address information will only be displayed when the network is first enabled and on
power up.
MultiLoad II Mobile Installation Guide: Version C
Description
The IP mask used to determine if an IP address is in the local network, or is on the other
side of the Gateway. Default is 255.255.255.0
The IP address of the network gateway used to access IP addresses outside the local
network. This should be set to the address of the cellular modem (by default,
192.168.13.31).
IP address of the Host (TDS) system.
Toptech Support.
This is a read only parameter and indicates the socket port number (7734) the Host
(TMS) system must connect to establish a serial connection across the serial port. The
type of socket connection is a SOCKET_STREAM.
Read only parameter indicating the socket address the Host (TMS) will use to
communicate with this serial port if it is configured as INTERNET. (7000)
Read only parameter indicating the Socket address the
communicate with this serial port if it is configured as INTERNET. (7001)
Read only parameter indicating the Socket address the
communicate with this serial port if it is configured as INTERNET. (7002)
Read only parameter indicating the Socket address client computers will use to contact
the built in HTTP server. (80)
M.u.l.t.i.L.o.a.d. .I.I. . .
............................Jan xx 2011
Copyright(c) 2000 Toptech Systems, Inc.
MAC Address: 00:50:c2:60:90:00
IP Address: 192.168.13.13
Net Mask: 255.255.255.0
Broadcast: 192.168.13.255
Gateway: 192.168.13.31
Host: 204.13.171.58
This information should be obtained from
Host(TMS)will use to
Host(TMS)will use to
v3.31.xx
