Chapter 6 – MutliLoad Configuration
For menu options and function screen items, pressing the Next key moves the selection bar down, and pressing
the Prev (Previous) key moves the selection bar up.
To return to the Main Menu, press EXIT. To return to any previous screen, press the EXIT key.
6.2.2 F M
IELD ODIFICATION AND
MultiLoad II will have all fields populated with default values. There are two types of fields, toggle or data entry.
Toggle fields contain a number of choices. Scroll through the choices by pressing the Enter key. Data entry
fields require that a value be entered into the field, within a given, applicable range. In the example below, RCU
Address field is highlighted.
Press ENTER to choose the field. A blinking cursor indicates data can be entered.
MultiLoad II Mobile Installation Guide: Version C
C O N F I G U R A T I O N
Communication
Network
RCU General Setup
RCU Setup
Equipment Setup
Alarm Setup
Products
Additive Cal.
Remote Adtv Cal.
Access ID's
Custom Logic
Customer Logo Setup
Date & Time
GPS Sites
Next Prev
D E
ATA NTRY
RCU GENERAL SETUP
RCU Address:
Card Reader Type:
Processing Mode:
Swing Arm Secondary:
Password #1:
Password #2:
Password #3:
Password #4:
Password #5:
Modem Dial:
Host Login: TDSTEST1TDSTEST1
Terminal SPLC: 123456001
Terminal Name: TDSTES1
Truck Number: T123456789
Next Prev
M E N U
Exit Enter
001
DISABLD
DISABLD
DISABLD
*******
*******
*******
*******
*******
Exit Enter
