6.3 N
ETWORK
Use the Network Setup function to define the network parameters for the Ethernet port.
Navigate to this screen as: Program Mode -> Configuration -> Network
The NETWORK SETUP screen displays:
After changes are made in this screen, exiting program mode is required for the changes to take effect.
Parameter
MAC Address
Network
IP Address
MultiLoad II Mobile Installation Guide: Version C
RCU Address:
Card Reader Type:
Processing Mode:
Swing Arm Secondary:
Password #1:
Password #2:
Password #3:
Password #4:
Password #5:
Modem Dial:
Host Login: TDSTEST1TDSTEST1
Terminal SPLC: 123456001
Terminal Name: TDSTES1
Truck Number: T123456789
Next
S
ETUP
MAC Address:
Network:
IP Address:
IP Mask:
IP Gateway:
IP Host:
Socket Port:
Com 0 Port:
Com 1 Port:
Com 2 Port:
HTTP Port:
Next
Description
This is a read only parameter and indicates the hardware MAC address of the Ethernet
port. This number is unique, assigned at the factory and cannot be modified.
Enables or Disables the Ethernet port. If the Ethernet port is enabled with no network
connected, startup may have a 10-20 second delay while the connection is checked.
Static IP address assigned to the unit. This value should come from the local network
administrator and should be unique to the local network. Dynamic IP address (DHCP)
is not supported. The recommended value based on the default modem configuration is
192.168.13.13.
RCU GENERAL SETUP
Prev Exit Enter

NETWORK SETUP

00:50:c2:60:90:00
ENABLED
192.168.13.13
255.255.255.0
192.168.13.31
204.13.171.58
7734
7000
7001
7002
80
Prev Exit Enter
