CHAPTER 6– CONFIGURATIONS
For menu options and function screen items, pressing the DOWN key moves the selection bar down,
and pressing the UP key moves the selection bar up.
To return to the Main Menu, press Exit. To return to any previous screen, press the Exit key.

Field Modification and Data Entry

MultiLoad II+/RCU II+ Firmware will have all fields populated with default values. There are two types
of fields, toggle, or data entry. Toggle fields contain several choices. Scroll through the choices by
pressing the DOWN or UP keys and OK to select. Data entry fields require that a value be entered into
the field within a given, applicable range. In the example below, RCU Address field is highlighted:
Press Enter to choose the field. A blinking cursor indicates that data can be entered.
Type in the new value (e.g. 123) and press Enter. The new value displays on the screen.
