RECEIVING THE FASTLANE POOL

The Fastlane Pool is shipped via UPS and contains at least 16
packages. Additional packages may be sent depending on the
options chosen:
(1) Hydraulic Power Unit
(Box labeled, "Power Unit Kit, 5Hp 60Hz, with Electronics, for
Poolside WQS with 3/12/09 Card 451000" for US Customers
and "Power Unit Kit, 5Hp 50Hz, with Electronics, for Poolside
WQS with 3/12/09 Card 451020" for International Customers)
(1) 5 Gallon Hydraulic Fluid
(1) Fastlane Pool Swim Unit Housing
(Box labeled, "Fastlane Upper Unit for Rolled Perf Base,
Sapphire 124016")
(1) Fastlane Pool Accessories Kit
(Box labeled Accessory Kit for Fastlane Pool w/ Rolled Perf
Base, Sapphire 124026)
Qty 2 - Hydraulic Hose Protective Channels
Qty 1 - Acrylic Top for Swim Unit
Qty 1 - Acrylic Hanging Bracket
Qty 1 - Lower Standoff
Qty 1 - Owner's Manual Kit (Padded Envelope)
Qty 1 - Owner's Manual
Qty 2 - Hydraulic Adapters (8 Female JIC x 6 Male JIC)
Qty 1 - Fastlane Pool Bonding Kit
Qty 38 - 3/4" 10-32 Machine Screws
Qty 10 - 1/2" 10-32 Machine Screws
Qty 4 - Rubber Grommets
Qty 6 - 10-32 nuts
(1) Fastlane Pool Swim Unit Base
(Box labeled Fastlane Lower Unit for Rolled Perf Base,
Sapphire 124011)
(1) Fastlane Pool Liner Box (Only for a 9x13 Pool)
(Box labeled, "Fastlane Pool Liner Box, 9 x 13 157070")
Qty 1 - Pool Liner
Qty 2 - Vertical Struts
Qty 4 - Top Corner Tubes
Qty 4 - Bottom Corner Tubes
(1) Fastlane Pool Liner Box (Only for a 9x17 Pool)
(Box labeled, "Fastlane Pool Liner Box, 9 x 17 157072")
Qty 1 - Pool Liner
Qty 4 - Vertical Struts
Qty 4 - Top Corner Tubes
Qty 4 - Lower Corner Tubes
Qty 2 - 130cm Top Straight Tubes
Qty 2 - Straight Bottom Tubes
(1) Fastlane Pool Strut Box
(Box labeled, "Fastlane Pool Strut Box 157067")
Qty 8 - Vertical Struts
(2) Fastlane Pool Tube Box
(Box labeled, "Fastlane Pool Tube Box 157068")
Qty 3 - 130cm Top Straight Tubes
Qty 2 - 60cm Top Straight Tubes
Qty 3 - Straight Bottom Tubes
(1) Fastlane Pool Equipment Hutch
(Box labeled, "Hutch Box for Fastlane Pool Equipment
157064")
Qty 1 - Equipment Hutch
Qty 1 - Equipment Mounting Board
Qty 1 - Pump Mounting Clamp
5
(1) Fastlane Pool Water Quality System
(Box labeled: Fastlane Pool, Skimmer Plumbing and start-up
Box with Teleweir Skimmer and Skimmer Housing [4302250])
Qty 1 - Skim-Filter
Qty 1 - Circulating Pump
Qty1 - Plumbing Parts bag
Qty 2 - Thru-wall Fittings
Qty 2 - MPT x Slip 90º Street Elbows
Qty 2 - Slip x Slip Unions
Qty 2 - Slip x Slip Ball Valves
Qty 2 - Pump Unions with O-Rings
Qty 1 - Male Slip x Female Slip 90º Street Elbow
Qty 2 - MPT x Insert 90º Elbow
Qty 2 - Plastic Hose Clamps
Qty 2 - Threaded Plug with O-Ring
Qty 1 - Eyeball Fitting
Qty 1 - 4oz PVC Cleaner
Qty 1 - 4oz PVC Cement
Qty 1 - Teflon Tape
Qty 1 - Liquid Tite Electrical Fitting
Qty 1 - 1-1/2" Slip x 1-1/2" Slip x 3/4" FPT Tee
Qty 1 - 3/4" Hose Spigot
Qty 1 - 2" Male Slip x 1-1/2"FPT Bushing Reducer
Qty 1 - Suction Fitting Assembly
Qty 1 - Skimmer Straight Nut
Qty1 - Fastlane Pool Start Up Bag
Qty 1 - Container of Test Strips
Qty 1 - Water Clarifier
Qty 1 - pH Increaser
Qty 1 - pH Decreaser
Qty 1 - Bag of Shock
Qty1 - Fastlane Pool Skim Filter Housing Assembly
Qty 1 - Skim Filter Housing
Qty 5 - 1/2" 10-32 Stainless Steel Machine Screws
Qty 5 - 1" Self Tapping Stainless Steel Screws
Qty 1 - 11/64" Drill Bit
Qty 1 - 3' Length of Suction Hose
(1) 50' Roll of Flexible PVC
(1) Fastlane Pool Ladder
(1) Solar cover
(only shipped if a Retractable Security Cover Kit was not
ordered)
(1) Optional Heater Controller
(Box labeled, "Fastlane Pool Heater Kit, 60Hz 157073" for
US Customers and, "International Fastlane Pool Heater Kit,
50Hz 157069" for International Customers)
Qty 1 - Heater Controller
Qty 1 - Keypad for Heater Controller
Qty 2 - Heater Tail Piece
Qty 2 - Heater Tail Piece T Gaskets
Qty 1 - Slip x Slip 90º Elbow
Qty 1 - Male Slip x Female Slip 90º Street Elbow
Qty 2 - 2-1/4" PVC Nipple
Qty 1 - 4-1/4" PVC Nipple
Qty 1 - Heater Controller Mounting Clamp
Qty 4 - 3/4" 10-32 Machine Screw
Qty 2 - 10-32 KEP Nut
