Endless Pools, Inc. provides for every aspect of a Fastlane Pool project. This manual assists in the installation process,
as well as the general maintenance of your Fastlane Pool.
Additional available resources including the Planning Guide and selected Supplemental Guides are available to you. These
documents are available online at www.myendlesspool.com/downloads.html. In addition, we encourage installers to call
our Customer Service Department at 800-910-2714 (US), 0800-520-0196 (UK) or 610-497-4538 (Direct) before beginning
installation to register their projects and sign up for weekend technical support.
Please be advised that gloves and safety goggles should be worn during the installation of a Fastlane Pool.
Shipping regulations have dictated that the following chemicals cannot be shipped to Alaskan, Hawaiian, or International cus-
tomers due to their hazardous nature: 4oz PVC cleaner, 4oz PVC Cement, 2 lb pH decreaser, and 1 lb bag of shock. If needed,
these chemicals will have to be obtained locally.
Please take into consideration the following before proceeding:
If you have purchased the Optional Heater/Controller package, that will require a 3-wire (w/ neutral) 220v, 30 amp,
GFCI power supply.
If you have purchased the standard package, then no neutral is required and the white wire can be left unused.
• The Submerged Suction Outlet Model #29-19 (part # 124011) is certified only for use with the Endless Pool Fastlane system.
It may not be used in any other application.
• This Submerged Suction Outlet Model #29-19 (#124011) may only be installed as described in this Manual. The Submerged
Suction Model #29-19 (part #124011), is 19" in diameter and 29" long and is constructed of 316L perforated stainless steel. It
should be replaced after 25 years using a #2 Phillips head screwdriver. It shall be marked with the following label: VGB 2008
SUBMERGED SUCTION 29-19, #124011. FOR USE ONLY WITH FASTLANE® SWIMMING MACHINE MANUFAC-
TURED BY ENDLESS POOLS, INC. LIFE: 25 YEARS, WALL ONLY. MAXIMUM FLOW FROM SINGLE 5 HP POWER
UNIT WITH ALP2-16 GEAR PUMP PRESET TO MAXIMUM FLOW OF 4.8 GPM UTILIZING 16" DIAMETER OPEN
FLOW PROPELLER. ENDLESS POOLS, INC. ANSI/APSP-16 2011
• The Submerged Suction Outlet Model #29-19 (part #124011) does not require routine service during the year or as part of
Endless Pool winterizing procedures.
• Before each use verify that the Submerged Suction Model #29-19 (part #124011), including the fasteners, is undamaged and
has not been tampered with.
• Do not use the Fastlane if there is any evidence of damage or tampering. Call the Endless Pools Customer Service Department
at 800 910 2714 immediately. The Submerged Suction Model #29-19 must be secured as described in this Manual before the
Fastlane is used again.
• Do not increase the flow through the Submerged Suction Model #29-19 (part #124011) by increasing the size of the pump.
• Please read and then keep these instructions for future reference.
Assembly Instructions
Note: all of the 316L stainless steel screws provided for the assembly of the Fastlane should be tightened to the recommended
25 in-lbs of torque.
Installation Instructions Table of Contents
Receiving the Fastlane Pool. . . . . . . . . . . . . . . . . . . . . . . . . 5
Pool Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Site and Pool Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pool Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Thru-Wall Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Skimmer Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Skimmer and Return Connections . . . . . . . . . . . . . . . . . . . . 9
Fastlane Swim Unit Assembly . . . . . . . . . . . . . . . . . . . . . . 10
Fastlane Hydraulic Power Unit Assembly . . . . . . . . . . . . . 13
Assembling the Water Quality System
Without Heater Controller . . . . . . . . . . . . . . . . . . . . . . . . . 13
Assembling the Water Quality System
With Heater Controller. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Electrical Requirements and Connections 60Hz . . . . . . . . 15
Electrical Requirements 50Hz . . . . . . . . . . . . . . . . . . . . . . 16
Bonding and Grounding. . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Fastlane Pool Equipment Hutch Assembly . . . . . . . . . . . . 17
Installing an Antenna Extension . . . . . . . . . . . . . . . . . . . . 17
Remote Control Transmitter. . . . . . . . . . . . . . . . . . . . . . . . 17
Initial Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Keypad Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Using the Fastlane Swim Unit . . . . . . . . . . . . . . . . . . . . . . 18
Caring for the Fastlane Pool . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Fastlane Pool Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Wiring Schematic 60Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Wiring Schematic 50Hz . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
