Wiring Diagram - Directed Directechs DB3 Installation Manual

Wiring diagram

Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Dash Fuse Box
(white conn.)
(+) 12V:
White, pin 1
1
D2D Port
(+) 12V input
(AC) Tach Intput
(-) Hood Pin Input
(-) Ground (-) Ground
(+) Accessory Output
(+) Starter 1 Output
(+) Ignition 1 Output
(+) Ignition 2 Output
6 403.TL10 2.32 2015 Toyota RAV4 (H Key)
©2023 Directed. All rights reserved.
Headlight Switch
10 9 8 7 6 5 4 3 2
20
19 18 17 16 15 14 13 12
Autolight: Green, pin 20
Cut
Hood Pin
(+) Starter:
(+) Ignition 1:
White, pin 2
White, pin 3
4 3 2 1
8 7 6 5
(+) Ignition 2: (+) Accessory:
Pink, pin 8 Red, pin 7
Ignition Connector
HS CAN High: Black, pin 6
HS CAN Low: White, pin 14
HS CAN High: Tan/Black: 3
1
11
TPMS Ignition Interrupt (conn. side): Yellow: 8
TPMS Ignition Interrupt (veh. side): Orange/Yellow: 9
Autolight Interrupt (conn. side): Orange/Red: 10
Autolight Interrupt (veh. side): Yellow/Red: 11
(AC) Tach Output: Violet/White: 5
SIL Data: Yellow/Black: 10
RDA: Orange/Black: 11
6 5 4
FUSES
16
18 17
30 29 28
BODY ECU
SIL Data: Green, pin 7
Diagnostic
1 8
Connector
6 7
OBDII
9 16
14
HS CAN Low: Tan: 4
Body ECU Connector
(underside conn. of ECU)
3 2 1
15 14 13 12 11 10 9 8 7
26
27 25 24 23 22 21 20 19
RDA: Lt. Blue or
Green, pin 16
).
