Directed Directechs DB3 Installation Manual page 9

Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
Additional remote start connections
(Not all of these connections may be required for your installation. Refer to the wiring diagram for vehicle-specific connections.)
Wire
12 Volts
Accessory
Hood Pin [1]
Ignition
Second Ignition
Starter
Tachometer [2]
9 403.TL10 2.32 2015 Toyota RAV4 (H Key)
©2023 Directed. All rights reserved.
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
(-) W2W Only - Right Slidding Door
(-) W2W Only - Left Slidding Door
No Connection
(+) W2W Only - Pk Light Input
No Connection
(+) W2W Only - Ignition Input
(-) W2W Only - Ground When Running (Status) Input
Color
Green
Black
Blue
Red
Color
N/A
N/A
Connects To
Wire Location
Dash Fuse Box, white 1 pin plug (3A), pin 1
Ignition Switch, white 8 pin plug, pin 7
Above Driver Kick, white 5 pin plug, pin 4
Ignition Switch, white 8 pin plug, pin 3
Ignition Switch, white 8 pin plug, pin 8
Ignition Switch, white 8 pin plug, pin 2
OBD-Data Link Connector, white 16 pin plug, pin 9
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
Remote Starter
Remote Starter
No Connection
Remote Starter
No Connection
Ignition Switch, white 8 pin plug, pin 3
Remote Starter
(+/-)
+
+
-
+
+
+
AC
(+/-) Wire Color
+ White
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
Wire Color
White (120A)
Red
Red (with remote start only)
White
Pink
White
Gray
