Machine control – Operating elements

Overview of control sections

4 Machine control – Operating elements
4.1 Overview of control sections
For description purposes, the machine control has been divided into three sections (A, B, C) to
ensure maximum clarity. The setting range for the parameter values are summarised in the
parameter overview section > see 8.1 chapter.
Item Symbol
1
2
3
16
Description 0
Control section A
> see 4.1.1 chapter
Control section B
> see 4.1.2 chapter
Control section C
> see 4.1.3 chapter
Figure 4-1
