5.3.1

JOB favourites

Favourites are additional locations for storing and loading frequently used welding tasks, programs and
their settings. The status of the Favourites (loaded, changed, not loaded) is indicated by signal lights.
• Five Favourites are available to save any settings.
• As required, the access control can be adjusted with the key switch or Xbutton function.
Item Symbol
1
2
5.3.1.1

Saving current settings to Favourites

• Press and hold the favourite memory push-button for 2 s (the signal light of the favourite status is
green).
5.3.1.2

Loading saved Favourites

• Press the favourite memory push-button (the signal light of the favourite status is green).
099-00T500-EW501
30.1.2023
Description 0
push-button - JOB Favourites > see 5.3.1 chapter
•-----------Pressing the push-button briefly: Loading Favourites
•-----------Press and hold the push-button (>2 s): Saving as a Favourite
•-----------Press and hold the push-button (>12 s): Deleting a Favourite
Signal light of Favourite status
---------- Signal light is green: Favourite loaded, settings of the Favourite and the cur-
rent device settings are identical
---------- Signal light is red: Favourite loaded, but settings of the Favourite and the cur-
rent device settings are not identical (for example, the operating point has
been changed)
------------ Signal light is off: Favourite not loaded (e.g. JOB number has been changed)
2s
Functional characteristics
Figure 5-47
Figure 5-48
Figure 5-49
Arc length restriction (USP)
