Functional characteristics

Arc length restriction (USP)

Selection
5.2.7

Pulse welding

5.2.7.1

Average value pulse welding

Average value pulse welding means that two currents are switched periodically, a current average value
(AMP), a pulse current (Ipuls), a balance (
predefined ampere current average value is decisive, the pulse current (Ipuls) is defined by the
meter as a percentage of the current average value (AMP). The pulse pause current (IPP) requires no
setting. This value is calculated by the machine control, so that the welding current average value (AMP)
is maintained at all times.
AMP = Main current; e.g. 100 A
Ipuls = Pulse current =
IPP = Pulse pause current
Tpuls = Duration of one pulse cycle = 1/
= Balance
5.3 Arc length restriction (USP)
The arc length restriction
ted (unusually large gap between electrode and workpiece). The function can be switched on or off de-
pending on the process > see 5.10 chapter.
58
Figure 5-45
) and a frequency (
Figure 5-46
x AMP; e.g. 140% x 100 A = 140 A
; e.g. 1/1 Hz = 1 s
function stops the welding process when an excessive arc voltage is detec-
4s
) having been defined first. The
