11.2 Parameter overview – setting ranges

11.2.1 TIG welding

Parameter
TIG/plasma
Gas pre-flow time
Start current AMP%
Up-slope time
Pulse time
Slope time
Secondary current AMP%
Pulse pause time
Slope time
Down-slope time
End current AMP%
Gas post-flow time
spotArc time
spotmatic time (
spotmatic time (
activArc
Up/down speed
Current jump
Pulse balance
Pulse frequency
099-000141-EW501
22.03.2023
Display
s
%
s
s
s
%
s
s
s
%
s
s
> ) ms
> ) s
%
A
%
Hz
Setting range Comment
0,5 0 - 20
20 1 - 200 % of main current AMP
1,0 0,0 - 20,0
0,01 0,00 - 20,0
0,10 0,00 - 20,0 Time from main current AMP to se-
condary current AMP%
50 1 200 % of main current AMP
0,01 0,00 - 20,0
Period from secondary current
0,10 0,00 - 20,0
AMP% to main current AMP
1,0 0,0 - 20,0
20 1 - 200 % of main current AMP
8 0,0 - 40,0
2 0,01 - 20,0
200 5 - 999
2 0,01 - 20,0
0 - 100
10 1 - 100 x0.01% of main current AMP
1 1 - 20
1 - 99 Pulsing, metallurgical
50 10 - 15000 Pulsing, metallurgical
