Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
T-Harness is not compatible.
compatible
Vehicle Takeover
Firmware notes
Remote Start: If the "3x LOCK/START" and "3x LOCK/STOP" features have been selected for this installation, you can also remote
Š
start the vehicle by pressing the lock button on the factory remote 3 times, with an interval of 1 second in between each button press
on the factory remote.
Key2GO is required if only one key is available. You can program the interface without the need for Key2GO if two keys are present.
Š
Š All connectors are displayed from the wire side (unless specified otherwise).
Š Refer to the "Vehicle connections" following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Tach: An optional connection required on some remote starters, which do not support a tach signal in D2D.
[3] Unlock Dectection Output: Required to wake up the system from sleep mode in vehicles without one-touch window control.
5
403.FORD4 3.25 2017 Ford Escape
©2023 Directed. All rights reserved.
Refer to the Quick Reference Guide section for more details.
Keys required for Keys required
1
programming for operation
0
