403.NISS4HT
DB3
v2.36
2023 Nissan Armada (Smart Key)
THNISS3D Compatible
(Sold Separately)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DIRECTECHS DB3 and is the answer not in the manual?

Questions and answers

Related Manuals for Directed DIRECTECHS DB3

Summary of Contents for Directed DIRECTECHS DB3

  • Page 1 403.NISS4HT v2.36 2023 Nissan Armada (Smart Key) THNISS3D Compatible (Sold Separately)

  • Page 2: Table Of Contents

    Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Installation Wiring diagram with T-Harness (THNISS3D) Wiring diagram Locating components in the vehicle Vehicle connections Module programming Key2GO Connecting the module LED diagnostics and troubleshooting Soft reset Hard reset Feature programming Feature and option list Limited one year consumer warranty Quick Reference Guide (customer copy)

  • Page 3: Introduction

    This module can only be flashed and configured using DirectLink at www.directechs.com or using the Directechs Mobile application for smartphones. Refer to “Connecting the module” for more information. 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 4: Vehicle Function Compatibilities

    Entry Monitoring Trunk/Hatch Pin Control of aftermarket alarm with OEM remote Brake Status (foot brake) Fuel level/EV battery level E-Brake Status Key2GO Ignition Status Immobilizer Bypass-Data No Key Req'd 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 5: Pre-Installation And Application Warnings

    [2] Tach: The tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D. 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 6: Wiring Diagram With T-Harness (Thniss3D)

    White/Black: N.C. (black 15-pin conn.) (+) Brake: Refer to the PTS Switch Red, pin 2 Additional mandatory connections (brown 8- pin conn.) section for connection details. XKD2D65 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 7: Wiring Diagram

    Yellow, pin 15 Gray/Red, pin 7 Clock: Pink, pin 2 (behind instrument cluster) (black 15-pin conn.) Data: Lt. Green/Red, pin 3 NATS Antenna Connector (white 4-pin conn. behind Push-to-Start button) 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 8: Locating Components In The Vehicle

    Locating components in the vehicle 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 9: Vehicle Connections

    Lt. Green/Red H2/12 Blue/Red (-) W2W Only - Hood Output Remote Starter Input 10-pin black connector (H3) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.
  • Page 10 Starter BCM behind instrument cluster, white 40 pin plug, pin 27 Red/White Tachometer [1] Power Steering Control Unit behind glove box, white 12 pin plug, pin Black/Lt. Blue 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 11: Module Programming

    Once the configuration is completed, reconnect the module. The LED turns ON solid green for 3 seconds, then turns OFF. You have successfully completed the module programming sequence. 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 12: Key2Go

    Any first-time user must re-register to gain access to Key2GO, and some additional information will be required to complete the registration process, such as your Directed account number and store name. Key2GO is compatible with XKLoader2 and the online web tool, as well as XKLoader3 and the Directechs Mobile application.

  • Page 13: Led Diagnostics And Troubleshooting

    External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.
  • Page 14 The smart key was not detected, which prevents the system from shutting down the vehicle. Flashes red x 3 Speed was detected. The vehicle was detected as moving, which prevents the system from shutting it down. Flashes red x 4 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 15: Soft Reset

    Wait 3 seconds until the LED turns ON solid orange, and wait 10 more seconds until the & LED starts to flash orange and red. Solid Flashes Release the programming button. The LED turns ON solid red. & Release Solid 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 16: Feature Programming

    To exit feature programming, press and hold the programming button for 3 seconds or ensure there is no activity on the interface for 30 seconds. The LED will turn ON orange for 2 seconds to confirm the end of the programming sequence. 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 17: Feature And Option List

    3. Enabled - Type2 Works for most North American vehicles. (We've noticed that some North American vehicles need to be set to (US)* "Type 1 (EU)" to work properly.) 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 18: Limited One Year Consumer Warranty

    This Warranty gives you specific legal rights and you may also have other rights which vary from state to state. VOXX DEI LLC, 2351 J. Lawson Blvd., Orlando, Florida 32824 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.

  • Page 19: Quick Reference Guide (Customer Copy)

    3 possible ways you can send commands to your vehicle, using the: in Park (P). • Factory remote. • Aftermarket remote. Press the Remote Start button on the transmitter.* • Directed SmartStart application via your smartphone. & Parking lights The parking lights will flash once to indicate the vehicle is Press...
  • Page 20 Notes 403.NISS4HT 2.36 2023 Nissan Armada (Smart Key) ©2023 Directed. All rights reserved.
