Vehicle Connections - Directed DB3 Installation Manual

Vehicle connections

The connection information listed below is specific to the 2017 Ford Escape. Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
8 403.FORD4 3.25 2017 Ford Escape
©2023 Directed. All rights reserved.
Description
No Connection
No Connection
(DATA) HS CAN High 2
(DATA) HS CAN Low 2
(DATA) HS CAN High 1
(DATA) HS CAN Low 1
Relay N.O. - (+) 12 Volt Input
Relay COM. - (+) Ignition Output
Relay N.C. - No Connection
Relay N.C. - RAP Off Interrupt (conn. side)
Relay COM. - RAP Off Interrupt (vehicle side)
Relay N.O. - No Connection
(+) W2W Only - 12 Volt
(-) W2W Only - Ground
Description
[4]
(-) Unlock Detection Output
(-) Lock Output
(-) W2W Only - Door/Trunk Output
(-) Unlock Output
[2]
(AC) W2W Only - Tach Output
No Connection
(+) Accessory Output
(MUX)
[3]
(-) Trunk / Hatch/ Power Liftgate Output
(Data) TX
(Data) RX
Connects To
Wire Location
No Connection
No Connection
BCM behind glove box, green 42 pin plug (A), pin 41
BCM behind glove box, green 42 pin plug (A), pin 40
BCM behind glove box, blue 60 pin plug (C), pin 7
BCM behind glove box, blue 60 pin plug (C), pin 8
BCM behind glove box, green 2 pin plug (G), pin 1
BCM behind glove box, blue 60 pin plug (C), pin 43
No Connection
BCM behind glove box, brown 60 pin plug (B), pin 45
BCM behind glove box, brown 60 pin plug (B), pin 45
No Connection
BCM behind glove box, green 2 pin plug (G), pin 1
Connects To
Wire Location
BCM behind glove box, brown 60 pin plug (B), pin 55
Required to wake up the system from sleep mode in vehicles without one-
touch window control.
BCM behind glove box, brown 60 pin plug (B), pin 36
Remote Starter
BCM behind glove box, blue 60 pin plug (C), pin 26
Remote Starter
An optional connection required on some remote starters, which do not
support a tach signal in D2D.
No Connection
BCM behind glove box, blue 60 pin plug (C), pin 44
No Connection
BCM behind glove box, brown 60 pin plug (B), pin 49
Not Applicable
Required on 2014-2015 Ford Escape. The 2016+ Ford Escape power
liftgate is in data.
BCM behind glove box, blue 60 pin plug (C), pin 54
BCM behind glove box, blue 60 pin plug (C), pin 34
(+/-) Wire Color
data gray/orange (MS CAN)
data violet/orange (MS CAN)
data white/blue (HS CAN)
data white (HS CAN)
+ red (50A)
+ brown/yellow
- N.C. green/violet
- N.C. green/violet
+ red (50A)
(chassis ground)
(+/-) Wire Color
- blue/brown
- gray/yellow
- violet/orange
+ violet/green
- brown (rear handle switch);
(LIN bus, power liftgate switch)
data yellow/orange
data violet/gray
