Directed DB3 Installation Manual page 9

Module
Conn./Pin Color
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
9 403.FORD4 3.25 2017 Ford Escape
©2023 Directed. All rights reserved.
Description
(-) W2W Only - Hood Output
Description
(-) W2W Only - Lock Input
(-) W2W Only - Unlock Input
(-) W2W Only - Trunk Input
No Connection
No Connection
No Connection
No Connection
(+) W2W Only - Starter Input
(+) W2W Only - Ignition Input
(-) W2W Only - GWR Input
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
Remote Starter
Connects To
Wire Location
Remote Starter
Remote Starter
Remote Starter
No Connection
No Connection
No Connection
No Connection
Remote Starter
Remote Starter
Remote Starter
(+/-) Wire Color
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
