Troubleshooting
7.1.3 Warning Words
Bit
Warning Word
(Hex)
(16-92 Warning Word)
00000001
00000002
Power card overtemperature
00000004
Earth fault
00000008
00000010
Control word timeout
00000020
Over current
00000040
00000080
Motor thermistor overtemperature.
00000100
Motor ETR over temperature
00000200
Inverter overloaded
00000400
DC-link undervoltage
00000800
DC-link overvoltage
00001000
00002000
00004000
Mains phase loss
00008000
No motor
00010000
Live zero error
00020000
00040000
00080000
00100000
00200000
00400000
00800000
24 V supply fault
01000000
02000000
Current limit
04000000
Low temperature
08000000
10000000
20000000
40000000
Not used
80000000
Not used
Table 7.3 16-92 Warning Word
®
VLT
DriveMotor FCP 106 & FCM 106 BACnet Operating Instructions
MG03O102 - Danfoss A/S © 12/2013. All rights reserved.
Bit
Warning Word 2
(Hex)
(16-93 Warning Word 2)
00000001
00000002
00000004
00000008
Reserved
00000010
Reserved
00000020
00000040
Dry Pump
00000080
End of Curve
00000100
Broken Belt
00000200
Not used
00000400
Reserved
00000800
Reserved
00001000
Reserved
00002000
Reserved
00004000
Reserved
00008000
Auto DC Braking
00010000
Reserved
00020000
Not used
00040000
Fans warning
00080000
00100000
Reserved
00200000
Reserved
00400000
Reserved
00800000
Reserved
01000000
Reserved
02000000
Reserved
04000000
Reserved
08000000
Reserved
10000000
Reserved
20000000
Back EMF too high
40000000
Reserved
80000000
Reserved
Table 7.4 16-93 Warning Word 2
