Parameters
8-35 Minimum Response Delay
Range:
8-36 Maximum Response Delay
Range:
Size
related 10.0 s]
*
6.2.3 8-5* Digital/Bus
6 6
Parameters for configuring the control word Digital/Bus
merging.
8-50 Coasting Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR Activates coast via the serial communication port
*
8-51 Quick Stop Select
Option:
[0] Digital
input
[1] Bus
22
Function:
overcoming modem turnaround delays.
Function:
[ 0.1 - Specify the maximum permissible
delay time between receiving a
request and transmitting the response.
If this time is exceeded, no response is
returned.
Function:
Select control of the coasting function via the
terminals (digital input) and/or via the bus.
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Activates coast via a digital input.
Activates coast via the serial communication
port.
Activates coast via the fieldbus/serial communi-
cation port, AND additionally via one of the
digital inputs.
OR via one of the digital inputs.
Function:
Select control of the Quick Stop function via the
terminals (digital input) and/or via the bus.
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Activates Quick Stop via a digital input.
Activates Quick Stop via the serial communi-
cation port.
MG03O102 - Danfoss A/S © 12/2013. All rights reserved.
®
VLT DriveMotor FCP 106 & FCM 106 BACnet Operating Instructions
8-51 Quick Stop Select
Option:
[2] Logic
AND
[3] Logic OR Activates Quick Stop via the serial communi-
*
8-52 DC Brake Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
8-53 Start Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR Activates Start command via the serial communi-
*
8-54 Reversing Select
Option:
Function:
Activates Quick Stop via the serial communi-
cation port, AND additionally via one of the
digital inputs.
cation port OR via one of the digital inputs.
Function:
Select control of the DC brake via the terminals
(digital input).
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Activates DC brake via a digital input.
Activates DC brake via the serial communication
port.
Activates DC brake via the serial communication
port, AND additionally via one of the digital
inputs.
Activates DC brake via the serial communication
port OR via one of the digital inputs.
Function:
Select control of the frequency converter start
function via the terminals (digital input).
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Activates Start command via a digital input.
Activates Start command via the serial communi-
cation port.
Activates Start command via the serial communi-
cation port, AND additionally via one of the
digital inputs.
cation port OR via one of the digital inputs.
Function:
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the serial communication port.
