Parameters
8-54 Reversing Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
[0] Digital Activates Reverse command via a digital input.
*
input
[1] Bus Activates Reverse command via the serial
communication port.
[2] Logic Activates Reverse command via the serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic Activates Reverse command via the serial
OR communication port OR via one of the digital
inputs.
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the serial communication port.
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
[0] Digital Activates the set-up selection via a digital input.
input
[1] Bus Activates the set-up selection via the serial
communication port.
[2] Logic Activates the set-up selection via the serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic Activate the set-up selection via the serial
*
OR communication port OR via one of the digital
inputs.
8-56 Preset Reference Select
Option: Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital
input) and/or via the serial communication port.
[0] Digital Activates Preset Reference selection via a digital
input input.
[1] Bus Activates Preset Reference selection via the
serial communication port.
[2] Logic Activates Preset Reference selection via the
AND serial communication port, AND additionally via
one of the digital inputs.
®
VLT DriveMotor FCP 106 & FCM 106 BACnet Operating Instructions
[3]
6.2.4 8-7* BACnet
1
127
1
[0]
[1]
admin
Size related
6.2.5 8-8* FC Port Diagnostics
These parameters are used for monitoring the Bus
communication via the FC Port.
0
MG03O102 - Danfoss A/S © 12/2013. All rights reserved.
8-56 Preset Reference Select
Option: Function:
Logic OR Activates the Preset Reference selection via the
*
serial communication port OR via one of the
digital inputs.
8-70 BACnet Device Instance
Range: Function:
[0 - 4194303 ] Enter a unique ID number for the BACnet
*
device.
8-72 MS/TP Max Masters
Range: Function:
[0 - 127 ] Define the address of the master which holds
*
the highest address in this network. Decreasing
this value optimises polling for the token.
8-73 MS/TP Max Info Frames
Range: Function:
[1 - 65534 ] Define how many info/data frames the device
*
is allowed to send while holding the token.
8-74 "I am" Service
Option: Function:
Send at Select when the device should send the "I-
*
power-up Am" service message only at power-up.
Continuously Select when the device should send the "I-
Am" service message continuously with an
interval of approx. 1 min.
8-75 Intialisation Password
Range: Function:
[1 - 1 ] Enter the password needed for execution of
*
Drive Re-initialisation.
8-79 Protocol Firmware version
Range: Function:
[0 - 65535 ] Read the supported protocol version.
*
Index 5 is for BACNet.
8-80 Bus Message Count
Range: Function:
[0 - 65536 ] This parameter shows the number of valid
*
telegrams detected on the bus.
