Xylem SI Analytics HandyLab 200 Operating Manual page 29

HandyLab 200
ba77063e03 01/2018
Menu item
Measurement /
Measuring cell /
Cell const. man
Measurement /
Measuring cell /
Cell const. LF313T
Measurement /
Temp. comp. (TC) /
Method
Measurement /
Temp. comp. (TC) /
Linear coeff.
Measurement /
Temp. comp. (TC) /
Reference temp.
Measurement / TDS
factor
Measurement /
Stability control
Measurement /
Temperature unit
Reset
Possible Explanation
setting
man Any measuring cells with
freely adjustable cell con-
stants.
0.250 ... Display and setting option of
-1
25.000 cm the cell constant of any mea-
suring cells (man).
0.090 to Display and setting options for
-1
0.110 cm the cell constant of the mea-
suring cell LF313T.
nLF Procedure for temperature
Lin compensation (see section
Off 4.4.3).
This setting is only available
for the measured parameters,
ϰ
and
0,000 ... Coefficient of the linear tem-
3,000 %/K perature compensation.
This setting is only available
when the linear temperature
compensation is set.
20 °C Reference temperature
25 °C
This setting is only available
for the measured parameters,
ϰ
and
0.40 ... 1.00 Factor for TDS value
On / Off Switches on or off the auto-
matic stability control during
measurement (see section
4.3.3)
°C Temperature unit,
°F degrees Celsius or degrees
Fahrenheit.
All temperature values are dis-
played with the selected unit.
- Resets all sensor settings to
the delivery condition (see
section 4.6.1).
Operation
ρ
.
ρ
.
29
