2.5. Multi I/O and Storage

USB
4x USB 3.0/2.0/1.1 (USB 0, 1, 2, 3)
SuperSpeed, High-Speed, Full-Speed and Low-Speed USB signaling
USB_OC pins share the same source, from SOC
SATA
2x SATA 6Gb/s (SATA 0,1)
Note: Combined HSIO has a bandwidth up to the equivalent of 16 PCIe Gen3 lanes; PCIe lane 0-15, SATA, GbE and USB SSTX/RX are sourced
from HSIO.
UART
Two UART interfaces SER0 and SER1 RX/TX on module
Console Redirection COM 1 or COM 2 selectable in BIOS
Up to 4 serial ports supported by standard BIOS, including Super I/O on carrier board
COM Port Description
COM 1
Supported by module (SER0, A98/A99), via embedded controller
COM 2
Supported by module (SER1, A101/A102), via embedded controller
COM 3
Supported by Super I/O (W83627DHG) on carrier board
COM 4
Supported by Super I/O (W83627DHG) on carrier board
SER0, SER1 from SoC HSUART are supported by BOM option and project basis
GPIO or SD
4 GPO and 4 GPI (GPI with interrupt, TBC)
Page 14
IRQ
4
3
5
7
Copyright © 2022 ADLINK Technology, Inc.
Address
Console Redirection Support
0x3F8
Yes
0x2F8
Yes
0x240
Yes
0x248
Yes
PICMG COM.0 R3.1
