Server Chassis Features

The 1010S-MR is a mini 1U rackmount server platform confi guration. The following
is a general outline of the main features of the SC512C-260 chassis.
System Power
When confi gured as a 1010S-MR, the SC512C-260 chassis includes a single 260W
power supply.
Control Panel
The SC512C-260's control panel provides important system monitoring and con-
trol information. LEDs indicate power on, network activity, hard disk drive activity,
overheat warning and fan failure. The control panel also includes a main power
button and a system reset button.
Rear I/O Panel
The rear I/O panel on the SC512C-260 provides one motherboard expansion slot,
one COM port (another is internal), two USB ports, PS/2 mouse and keyboard ports,
a graphics port and two Gb Ethernet ports. (See Figure 1-2.)
Cooling System
The SC512C-260 chassis has an innovative cooling design that features a 10-cm
blower system cooling fan. The blower fan plugs into a chassis fan header on the
motherboard and operates at full rpm continuously.
