AS1010S-MR User's Manual
6-5

Power Supply

The 1010S-MR has a single 260 watt power supply. This power supply has the
capability of operating at 100 - 240 input volts. Power down the system and then
unplug the AC power cord to completely remove power from the system before
removing the power supply.

Power Supply Failure

If the power supply unit fails, the system will shut down and you will need to re-
place the power supply unit. Replacement units can be ordered directly from the
manufacturer (PWS-0055 - see contact infomation in Chapter 1).

Replacing the Power Supply

1. Accessing the inside of the system
To replace a power supply, you must fi rst remove the top chassis cover. To do so,
fi rst grasp the two handles on either side and pull the unit straight out until it locks
(you will hear a "click"). Next, depress the two buttons on the top of the chassis to
release the top cover and push it away from you. You can then lift the top cover
from the chassis to gain full access to the inside of the server.
2. Removing the power supply
First unplug the power cord from the system. To remove the failed power unit,
remove the two screws on the back of the power supply and a third from the front
of the power supply, which secures it to the bottom of the chassis. You can then
lift the unit straight out of the chassis. (The power cord should have already been
removed.)
3. Installing a new power supply
Replace the failed unit with another unit of the same wattage. It is highly recom-
mended to replace it with the exact same power supply. Carefully insert the new
unit into position in the chassis and secure it with the two screws at the rear of the
unit and the third at the front. Then reconnect the power cord, replace the chas-
sis top cover and push the unit back into the rack. Finish by turning the power
switch on the power supply on, and then depress the power button on the front of
the system.
